Volume pot is 500K log, tone pot is 500K linear
C1 - 47nF Mylar
C2 - 82pF ceramic
The neck and middle pickup switches are SPST, bridge pickup
switch is DPDT. (There is no apparent reason for this, 3 of the connectors
are not used so an SPST switch could be used instead)
Pickups - Neck 5.44K, middle 5.37K, bridge humbucker 11.07K (5.53K when coil-tapped)
